Запчасти Bobcat BACKHOE BACKHOE (Dipper Cylinder) (913) 913 BACKHOE

1

CYLINDER See Illustration BACKHOE/ B20584 - NLA - W/Ref. 2-18 - Order 6529696 - Was 6594192 - A

2

ROD See Illustration BACKHOE/ B20584 - NLA - Order 6529698, 6529703, 18C2044, & 27E20

3

6593285

HEAD

4

PISTON See Illustration BACKHOE/ B20584 - NLA - Order 6529698, 6529703, 18C2044 & 27E20 - Was 6593286 - A

5

86D20

NUT

6

6594123

CASE

7

6593381

SEAL

8

25K30308

O RING 10

9

58K340

O RING 10

10

73K340

BKUP RING back-up

11

6538277

SEAL

12

6686998

WIPER, ROD CYL Was 6666545 - A

13

47K5

PLUG W/Ref. 14 - flat boss face - A

13

90KV5

PLUG W/Ref. 14 - tapered boss face

14

79K6

O RING 10 for flat boss face

14

95K6

O'RING for tapered boss face

15

6594193

TUBE

16

17K7

ELBOW

17

79K10

O RING 10

18

57D5

NUT

19

6529595

SPACER

20

7008352

SEAL, QUAD

21

7196480

KIT, SEAL Ref. 7, 8, 11, 12 & 20 - Was 7137574 - A
