Запчасти Bobcat BACKHOE BACKHOE (Quick Disconnect) (914) (914A) 914/914A BACKHOE

1

KIT NLA - Order Ref. 2-20 - individually - Was SALES - A

2

7D10

NUT

3

25E25

WASHER 10

4

6503956

SPRING

5

6592705

BOLT

6

17C632

BOLT 5

7

6508407

BLOCK pin locking - right

8

6502030

LINKAGE

9

81D6

NUT

10

17C1256

BOLT

11

663350

PIN hinge

12

1F416

PIN

13

6502032

LEVER

14

61D12

NUT

15

23E12

WASHER Was 4E12 - A

16

6546790

BLOCK pin locking - left

17

17C1224

BOLT

18

25E27

WASHER

19

6504326

PIN

20

6504474

PIN
