Запчасти Bobcat BACKHOE BACKHOE (Dipperstick Section) (914) 914/914A BACKHOE

1

947633

SECTION Ref. 7-15, 20 & 22-28

2

947743

BOLT

3

4E6

WASHER

4

58K28

O RING 10

5

25K20104

O RING 10

6

58K024

O-RING 10

7

947718

PLUNGER

8

1550482

SPRING

9

25K30016

O RING 10

10

6632473

PLUG W/Ref. 9 - Was 947754B - A

11

947759

PLUG W/Ref. 12

12

25K30028

O RING 10

13

947737

SPRING

14

947717

PLUNGER

15

25K40024

O RING 10

16

25K30018

O RING 10

17

WASHER NLA - back-up - Was 80K000113B - A

18

25K30026

O RING 10

19

947751

PLUG W/Ref. 18

20

BODY & SPOOL NSS

21

RELIEF VALVE NSS - W/Ref. 18 - Was 947638B - A

22

25K30024

O RING 10

23

947745

RETAINER

24

947749

WASHER

25

947738

SPRING

26

947750

SCREW

27

947710

CAP ASSY

28

6631988

SCREW

29

948308

KIT Ref. 12, 15 - 15 & 22

30

948311

SEAL KIT between sections - Ref. 4-6 - one kit per valve bank
