Запчасти Bobcat BACKHOE BACKHOE (Buckets) (W/4 (101,6 mm) Cutting Edge) (911) 911 BACKHOE

1

BUCKET SALES - standard - 12'' (304,8 mm)

1

BUCKET SALES - standard - 16'' (406,4 mm)

1

BUCKET SALES - standard - 30'' (762 mm)

1

BUCKET SALES - standard - 36'' (914,4 mm)

2

6592051

EDGE, CUTTING WELD ON BEVELED 12.34'' 12'' (304,8 mm)

2

6592053

EDGE, CUTTING WELD ON BEVELED 16.22'' 16'' (406,4 mm)

2

6592054

CUTTING EDGE 30'' (762 mm)

2

6592055

CUTTING EDGE 36'' (914,4 mm)

3

6542987

CUTTING EDGE L.H. - 12'' (304,8 mm), 16'' (406,4 mm), 30'' (762 mm), 36'' (914,4 mm)

3

6542986

CUTTING EDGE R.H. - 12'' (304,8 mm), 16'' (406,4 mm), 30'' (762 mm), 36'' (914,4 mm)

4

6544633

CUTTING EDGE L.H.

4

6544634

CUTTING EDGE R.H.

5

6515119

SHANK

6

1550017

TOOTH, BUCKET 25

7

6518120

SHANK

8

BUCKET SALES - ribbed - 20'' (508 mm)

8

BUCKET SALES - ribbed - 24'' (609,6 mm)

9

BUCKET SALES - open side - 12'' (304,8 mm)

9

BUCKET SALES - open side - 16'' (406,4 mm)

10

6630424

TOOTH Was 1553699 - A

11

562660

PIN

12

6592216

CUTTING EDGE 20'' (508 mm)

12

6592217

EDGE, CUTTING WELD-ON SIDE 24'' (609,6 mm)

13

6657330

TOOTH Use W/Ref. 7

14

6657328

TOOTH Use W/Ref. 7

15

6657329

TOOTH Use W/Ref. 7

16

6586756

KIT to convert 911 buckets to 811 buckets - W/Ref. 17-19

17

6586757

PLATE

18

6560596

BUSHING

19

6722243

INSTRUCTION

19

6722243AR

INSTRUCTION translated - SEE NOTE - for Ref. 16

19

6722243BR

INSTRUCTION translated - SEE NOTE - for Ref. 16

20

6718778AR

KIT translation - SEE NOTE - for Ref. 16

20

6718778BR

KIT translation - SEE NOTE- for Ref. 16
