Запчасти Bobcat BACKHOE BACKHOE (Mounting Kits) (709 2700 & A54M) (709FDS 5841 & A5F3) 709 BACKHOE

1

6586933

KIT 740 Series - Ref. 2-5 & 15 - Was Sales - A

2

MOUNT NLA - LH - 740 Series - Order 6586934 & 6586937 - Was 6538068 - A

3

MOUNT NLA - RH - 740 Series - Order 6586934 & 6586937 - Was 6538070 - A

4

53D10

NUT Was 83D000010B - B

5

31C1028

SCREW

6

6586933

KIT 740 Series - Ref. 4, 5, 7, 8, 15, 23 & 24 - Was Sales - A

7

MOUNT NLA - LH -740 Series - Order 6586934 & 6586937 - Was 6538661 - A

7

6586934

MOUNT LH - 740 Series

8

MOUNT NLA - RH - 740 Series - Order 6586934 & 6586937 - Was 6538673 - A

8

6586937

MOUNT RH - 740 Series

9

KIT SALES #6533179 - 753 - Ref. 4, 5, 10, 11 & 16

10

MOUNT NLA - L.H. - 753 - Order 6538554 & 6538553 - Was 6532964 - A

11

MOUNT NLA - R.H. - 753 - Order 6538544 & 6538553 - Was 6532980 - A

12

6538707

MOUNT KIT 753 & S130 - Ref. 4, 5, 13, 14, 16, 21, 22, 30, 31, 43 & 44 - Was SALES - D

13

6538554

MOUNT L.H. - 753

14

6538553

MOUNT R.H. - 753

15

6720596

INSTRUCTIONS 740 Series

16

6720391

INSTRUCTIONS 753, 7753 & 773

17

6539094

BALL

18

KIT SALES #6539674 - 7753 - Ref. 4, 5, 16, 19 & 20

19

6539675

MOUNT R.H. - 7753 & 773

20

6539678

MOUNT L.H. - 7753 & 773

21

6586470

STOP boom - 753

22

73G620

SCREW 753

23

6579639

DECAL 753

24

6579509

DECAL 753

25

6587074

SPACER 753

26

6587606

MOUNT KIT 853 & 863 - Ref 4, 5 & 27-29 - Was SALES - D

27

6587607

MOUNT L.H. - 853 & 863

28

6587608

MOUNT R.H. - 853 & 863

29

6720806

INSTRUCTIONS 853 & 863

29

6720806AR

INSTRUCTIONS translated - For Ref. 26

29

6720806BR

INSTRUCTIONS translated - For Ref. 26

30

6718713AR

KIT translation - For Ref. 26

30

6718713BR

KIT translation - For Ref. 26

31

6718718AR

KIT trans - For Ref. 12 & 18

31

6718718AR

KIT trans - For Ref. 12 & 18

31

6718717AR

KIT decal - For Ref. 12 & 18

31

6718717BR

KIT decal - For Ref. 12 & 18

31

6718717JP

KIT decal - For Ref. 12 & 18

32

KIT SALES #7101325 - S150, S160 & T180 - Ref. 33-38

33

7101399

MOUNT R.H.

34

7101400

MOUNT L.H.

35

6902798

INSTRUCTIONS for Ref. 32

36

6717707

PIN

37

31C836

BOLT

38

63D8

NUT

39

17C640

BOLT 5

40

85D6

NUT, 5

41

6702301

DECAL, DANGER

42

6702302

DECAL, DANGER

43

6718392

DECAL, DANGER

44

6718393

DECAL, DANGER
