Запчасти Bobcat BACKHOE BACKHOE (Main Frame Tip Up Seat) (908) 908 BACKHOE

1

BOOM See Illustration BACKHOE/ D1112

2

6502468

SPIKE

3

1F420

CTTR PIN

4

6517955

HINGE PIN

5

6517954

PAD stabilizer - L.H.

5

6518553

PAD stabilizer - R.H.

6

62D20

NUT

7

6517978

GUIDE rack

8

6517953

PIN

9

SPACER NLA - Was 6517952 - A

10

710822

RING

11

6517982

PIN

12

6517983

STABILIZER

13

CONTROL ASSY. See Illustration BACKHOE/ B20447

14

4E6

WASHER

15

17C620

BOLT

16

CYLINDER See Illustration BACKHOE/ C1203 stabilizer

17

6517981

COVER foot

18

84G3112

BOLT 5 Was 14G-512 - D

19

STOP See Illustration BACKHOE/ B20455 lift arm

20

6504729

BRACKET

21

6515499

PIN safety

22

6500774

SEAT

23

1F416

PIN Was 1F-412 - D

24

25E18

WASHER

25

6504391

PIN

26

6540283

BRACKET

27

17C716

BOLT

28

4E7

WASHER

29

6540286

BRACE

30

17C624

BOLT 5

31

6540287

BRACE

32

6540288

BRACE

33

6517979

COVER

34

4E10

WASHER

35

61D10

NUT

36

6502401

PIN

37

PIN NLA - Was 1F820 - A

38

FRAME NLA - mounting - Order Ref. 48

39

17C512

BOLT 5

40

61D6

NUT 5

41

6513633

PIN

42

61D12

NUT

43

23E12

WASHER Was 4E12 - A

44

17C1244

BOLT

45

FRAME NLA - Was 6517950 - A

46

15C10104

SCREW

47

17C1024

BOLT

48

6546983

FRAME bob-tach mounted

49

6502400

HOOK mounting - weld on

50

6557836

RIVET

51

6518997

HOUSING upper bearing - weld on

52

6546986

PIN

53

1F632

PIN

54

6558039

SAFETY TREAD

55

6502750

DECAL caution

56

6552174

DECAL mounting instructions

57

6596591

DECAL warning - Was 6562925 - A
