Запчасти Bobcat 3 POINT HITCH 3 POINT HITCH (Category ll) (H702 6650) Loader

1

6586152

BLOCK

2

6586138

TUBE

3

6538285

LOCK RING

4

6584872

WASHER

5

6586153

PIN

6

6530889

HOSE

7

6529349

CYLINDER See Illustration 3 POINT HITCH/ B11769

8

FRAME NLA - Was 6586127 - A

9

17C828

BOLT

10

6586146

PIN

11

6649496

CLICK PIN

12

6586151

PIN

13

1321168

RING

14

742053

WASHER

15

6645240

TURN BUCKLE W/Ref. 50-53

16

6645234

LINK

17

6645241

TURN BUCKLE W/Ref. 54-57

18

6586145

LINK

19

6586142

LINK

20

6658499

CYLINDER See Illustration 3 POINT HITCH/ B14181

21

6561326

PIN

22

6645236

SNAP PIN

23

6645238

PIN

24

10H25

FITTING, GREASE 5

25

743108

FITTING

26

79K8

O RING 10

27

COUPLER NLA - Order 6667805 & 6667806 - Was 6630092 - A

28

COUPLER NLA - Order 6667805 & 6667806 - Was 6630093 - A

29

6583862

DECAL, WARNING

30

6531654

DECAL

31

31C832

BOLT

32

23E5

L WASHER

33

61D5

NUT

34

6657353

RIVET

35

1547283

LATCH ASY Was 6658474 - A

35

1F308

PIN, COTTER if equipped

36

6658475

COVER

37

17C552

BOLT

38

TRIM NLA - Was 6658476 - A

39

6658477

MOUNT PLATE

40

VALVE See Illustration 3 POINT HITCH/ B20025

41

STAND NLA - Was 6658479 - A

42

6658480

CYLINDER See Illustration 3 POINT HITCH/ B14182

43

6658481

HOSE

44

6658482

HOSE

45

6658483

HOSE

46

17C620

BOLT

47

23E6

WASHER

48

61D6

NUT 5

49

BUNGIE CATCH NSS - W/Ref. 35

50

6652810

TUBE

51

7D16

NUT

52

6652812

SCREW ASSY R.H.

53

6652811

SCREW ASSY. L.H.

54

6652807

SCREW ASSY. L.H.

55

6652808

TUBE

56

7D12

NUT

57

6658209

PULLEY

58

6539177

DECAL installation
