Запчасти Bobcat CT335 BEVEL GEAR CASE GROUP (Single Steering Cylinder) DRIVE TRAIN

Схема запчастей Bobcat CT335 - BEVEL GEAR CASE GROUP (Single Steering Cylinder) DRIVE TRAIN

Артикул

Название

Примечание

Количество

1

7013083

HOUSING, BEVEL GEAR

2

7012996

HOUSING, GEAR ASSY

3

6694360

PLUG, FILL

4

6694128

WASHER SEAL

5

7013082

GAUGE, OIL ENG

6

6696393

PIN STRAIGHT

7

6696279

O-RING

8

7002687

STUD

9

7012818

BOLT

10

6696242

NUT

11

6694094

WASHER SPRING

12

7002175

SEAL, FLOATING Ref. 13 & 14

13

7002361

RING, SEAL

14

7002594

ORING

15

7002471

BEARING

16

7012997

SUPPORT, AXLE FRONT

17

7002288

SEAL, OIL

18

6695528

BOLT

19

6697776

WASHER SPRING

20

7002459

SHIM

21

7002461

SHIM

22

7002464

SHIM

23

7002467

SHIM

24

6694227

FITTING, GREASE

Выбрано товаров: 24
