Запчасти Bobcat ZX75 HYDRAULIC INSTALLATION - BOOM HIGHT LIMITATION Circular Boom - Previous Version HYDRAULIC SYSTEM

1

5320001001

CONTROL VALVE W/Ref. 12

2

1008707115

BOLT M 6X90

3

1343707055

WASHER 6,4

4

1212251009

NUT M 6

5

6190241017

MOUNTING PLATE

6

1008707018

BOLT M 8X20

7

1343707057

WASHER 8,4

8

1915060255

FITTING

9

1919060351

FITTING

10

4256033371

HOSE, HYD Was 4506033351 - A

11

4506115351

HOSE ASSEMBLY CPL.

12

5320001002

SOLENOID CARTRIDGE

13

6190241015

BRACKET

14

1008707612

BOLT M 6X12

15

6190241016

ANGLE

16

1008707213

BOLT M 6X20

17

1901003709

PIPE CLIP

18

1919060151

FITTING

19

5000136710

HOSE CLIP 10,7

20

1008707517

BOLT M 8X12

21

6190241012

SEGMENT

22

1008707912

BOLT M 6X16
