Запчасти Bobcat ZX125 BUCKET 350,450,600,750,900,1000,1500 MM QUICKLY RELEASABLE ACCESSORIES & OPTIONS

1

6202735000

BUCKET 350mm W/Ref. 2-4

2

0202735005

BLADE, SIDE RIGHT

3

0202735006

BLADE, SIDE LEFT

4

6202735007

BLADE 350mm W/Ref. 5-7

5

5455660441

TOOTH HOLDER

6

5455660440

TOOTH TIP

7

5455660442

FUSE

8

6202741000

BUCKET 450mm W/Ref. 5-7 & 9-12

9

0202741005

BLADE, SIDE RIGHT

10

0202741006

BLADE, SIDE LEFT

11

6202741020

BLADE 450mm W/Ref. 5-7

12

0202760018

CUTTING EDGE

13

6202760000

BUCKET 600mm W/Ref. 5-7, 12 & 14-16

14

0202760006

BLADE, SIDE RIGHT

15

0202760005

BLADE, SIDE LEFT

16

6202760020

BLADE 600mm W/Ref. 5-7

17

6202773000

BUCKET 750mm W/Ref. 5-7, 12, 14, 15 & 18

18

6202773020

BLADE 750mm W/Ref. 5-7

19

6202790000

BUCKET 900mm W/Ref. 5-7, 12, 14, 15 & 20

20

6202790020

BLADE 900mm W/Ref. 5-7

21

6202767000

DITCH CLEANING BUCKET 1500mm W/Ref. 22-25

22

6210908007

CUTTING EDGE

23

6155267008

CUTTING EDGE

24

6210908008

CUTTING EDGE

25

6210908009

CUTTING EDGE

26

6209710000

BUCKET 1000mm W/Ref. 5-7, 12, 14, 15 & 27

27

6209710020

BLADE 1000mm W/Ref. 5-7
