Запчасти Bobcat E85 SLEW MOTOR HYDRAULIC SYSTEM

1

7028990

MOTOR, SLEW W/Ref. 2-66

2

7024785

HOUSING, VALVE

3

7007392

SHAFT DRIVE

4

7007234

BEARING ROLLER

5

7007403

BEARING BALL

6

7007404

SEAL OIL

7

7024786

PLATE, SHOE

8

7007387

PLATE RETAINER

9

7007410

PISTON ASSY

10

CASING NLA - Order Ref.1

11

7007388

BALL THRUST

12

7007054

WASHER

13

7007389

ROLLER

14

7004015

WASHER

15

7007390

SPRING

16

7007884

RING SNAP

17

7007411

BLOCK CYLINDER

18

7003820

PLATE FRICTION

19

7003821

PLATE MATING

20

7007393

PISTON BRAKE

21

7007391

SPRING BRAKE

22

7029305

PLATE, VALVE

23

7007218

ROLLER PLUNGER

24

7007219

SPRING CHECK

25

7007199

PLUG

26

7007848

PIN PARALLEL

27

7004658

O-RING

28

7004659

O-RING

29

7004660

O-RING

30

7004661

O-RING

31

7007911

O-RING

32

7007906

O-RING

33

7007757

BOLT SOCKET

34

7007731

BOLT SOCKET

35

7029307

PLUG

36

7004675

PLUG

37

7007873

RING SNAP

38

7029482

VALVE, RELIEF

39

7029472

VALVE, BRAKE

40

7028808

DIPSTICK, OIL

41

7029257

PIN, STRAIGHT

42

7024791

SHAFT

43

7007451

BEARING TAPER ROLLER

44

7007405

BEARING TAPER ROLLER

45

7007406

SEAL OIL

46

7007396

COVER BEARING

47

7007203

COLLAR HALF

48

7028872

CARRIER, PINION

49

7028871

CARRIER, PINION

50

7029253

PIN

51

7024794

RING, INNER

52

7024795

BEARING, NEEDLE

53

7007233

BEARING NEEDLE

54

7024796

GEAR

55

7024797

GEAR

56

7007400

GEAR SUN NO.2

57

7007210

GEAR NO.1 SUN

58

7007212

WASHER NO.1 THRUST

59

7024798

PLATE

60

7007325

WASHER THRUST

61

7007873

RING SNAP

62

7004674

PLUG PT3/8

63

7004671

PLUG PT 1/8

64

7024800

PIN, SPRING

65

7007760

BOLT SOCKET

66

CASE,VALVE NLA - Order Ref.1

67

7029054

KIT, GEAR & SHAFT W/Ref.10, 42-65

68

7024872

CARRIER, MOTOR W/Ref.49, 51, 53, 55, 58, 60, 61

69

7028870

GEAR, IDLE ASSY W/Ref.48, 50, 52, 54, 59, 64

70

7007415

KIT, SEAL W/Ref. 27-31, 45
