Артикул
Название
Примечание
Количество
1
24K3
PLUG W/O boom load hold option
1
FITTING See Illustration LOAD HOLD KIT/ NA2639 W/ boom load hold option
1
79K4
O RING 10
2
6697935
VALVE, PEDAL DUAL See Illustration TRAVEL CONTROLLER/ NA2307
3
LEVER, JOYSTICK W/PWM See Illustration LH JOYSTICK/ NA2224
4
7175187
HOSE, HYD
5
7175188
HOSE, HYD
6
7175189
HOSE, HYD
7
7175190
HOSE, HYD
8
10L0604
FITTING, HYD CONNECTOR
8
78K4
O'RING
8
7011053
CLIP
9
JOYSTICK, BLADE See Illustration BLADE JOYSTICK/ NA2339
10
10L0606
FITTING, HYD CONNECTOR
10
78K6
O'RING
10
7011053
CLIP
11
6624289
STRAP, TIE
12
6674264
RETAINER NUT
13
6676535
COUPLER
14
6678669
STRAP
15
6678818
MOUNT
16
6701097
WASHER
17
7010203
PUMP, HYD PISTON See Illustration HYDRAULIC PISTON PUMP/ NA5010
19
7176628
GROMMET
20
7178046
HOSE, HYD
21
7178048
HOSE, HYD
22
7178082
BRACKET
23
15KB0404
FTG HYD S Connector
23
79K4
O RING 10
24
17C620
BOLT
25
19J16
FLANGE
26
28CM1030
BOLT
27
43DM10
NUT
29
15KB0406
FTG HYD S CONNECTOR
29
79K6
O RING 10
30
21KB1210
FITTING, HYD TEE
31
36K8
CAP
32
6630367
CAP
33
7000009
PLUG
34
VALVE, CONTROL See Illustration HYDRAULIC CONTROL VALVE/ NA2567
35
7157717
TEE
36
7176310
TUBELINE, HYD
37
17KB0606
FITTING
37
79K6
O RING 10
38
21KB1212
FITTING, HYD TEE
39
24K3
PLUG W/O hydraulic X-Change
39
FITTING See Illustration X-CHANGE/ NA2581 W/ hydraulic X-Change
39
79K4
O RING 10
40
6661753
PLUG
41
7176176
TUBELINE, HYD
42
7176177
TUBELINE, HYD
43
7176300
TUBELINE, HYD
44
7023283
MANIFOLD, HYD ASSY See Illustration MANIFOLD ASSY/ NA1975 - Was 7176625 - A
45
7179003
HOSE, HYD
46
7176175
TUBELINE, HYD
47
7176294
TUBELINE, HYD
48
19KB0606
TEE
48
79K6
O RING 10
49
7152908
SWIVEL, HYD ASSY See Illustration SWIVEL ASSY/ NA2346
50
51DM8
NUT
51
24K5
PLUG W/O 2nd aux
51
FITTING See Illustration SECONDARY AUXILIARY KIT/ NA2582 W/ 2nd aux
51
79K6
O RING 10
52
24K5
PLUG W/O hydraulic X-Change
52
FITTING See Illustration X-CHANGE/ NA2581 W/ hydraulic X-Change
52
79K6
O RING 10
53
7176295
TUBELINE, HYD
54
7176174
TUBELINE, HYD
55
29CM825
BOLT
56
7178153
MOUNT
57
24K5
PLUG if equipped
57
79K6
O RING 10
Выбрано товаров: 76
