Запчасти Bobcat E35 HYDRAULIC CONTROL VALVE (10 Section Assembly) (W/ Angle Blade) HYDRAULIC SYSTEM

1

VALVE, CONTROL NLA - Ref. 2-26, & 28-35 - Order 6698641 valve - Also Order 7197061 hose and 6812864 tee if machine had arm load hold option and control valve W/dual port cap on arm section - Was 66986

1

6698641

VALVE, CONTROL Ref. 2-27 & 29-35 - Also Order 7197061 hose and 6812864 tee if machine had arm load hold option and control valve W/dual port cap on arm section

1

7019170

CONTROL VALVE Ref. 2-27 & 29-35

1

7229359

VALVE, CONTROL Ref. 2-27 & 29-35

2

7012780

ROD, TIE

3

7012685

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1981 inlet

4

7012686

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA5009 boom swing

5

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1983 slew

6

7012688

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1984 blade

7

7012689

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1985 LH travel

8

7012690

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1986 RH travel

9

7012781

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA5009B angle blade

10

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1987 boom

11

7012692

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA5009A aux

12

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1982 arm

13

7012694

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1988 bucket

14

7012695

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1989 outlet

15

7012696

VALVE, RELIEF W/Ref. 24

16

7012697

VALVE, RELIEF W/Ref. 24

17

7012698

VALVE, ANTI CAV

18

7012699

VALVE, SHUTOFF HYD

19

7012700

PLUG W/Ref. 23

20

7012701

VALVE, RELIEF W/Ref. 24

21

6653123

NUT

22

7012765

RING, BACK-UP

23

O-RING NSS

24

7012763

O-RING

25

7012773

O-RING

26

7012766

O-RING

27

7012698

VALVE, ANTI CAV

28

VALVE, SHUTOFF HYD NLA - Order Ref. 27

29

7012767

SPRING, VALVE

30

7012768

POPPET

31

7012769

PLUG

32

7012770

SET SCREW

33

7012771

NUT

34

7012772

PLUG

35

7012774

POPPET
