Запчасти Bobcat E32 HYDRAULIC CONTROL VALVE (Assembly) HYDRAULIC SYSTEM

1

VALVE, CONTROL NLA - Ref. 2-25, & 27-34 - Order 6698126 valve - Also Order 7197061 hose and 6812864 tee if machine had arm load hold option and control valve W/dual port cap on arm section - Was 66981

1

6698126

VALVE, CONTROL Ref. 2-26 & 28-34 - Also Order 7197061 hose and 6812864 tee if machine had arm load hold option and control valve W/dual port cap on arm section

1

7019169

CONTROL VALVE Ref. 2-26 & 28-34

1

7229358

VALVE, CONTROL Ref. 2-26 & 28-34

2

7012684

ROD, TIE

3

7012685

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1981 inlet

4

7012686

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA5009 boom swing

5

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1983 slew

6

7012688

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1984 blade

7

7012689

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1985 LH travel

8

7012690

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1986 RH travel

9

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1987 boom

10

7012692

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA5009A aux

11

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1982 arm

12

7012694

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1988 bucket

13

7012695

SECTION, VALVE See Illustration HYDRAULIC CONTROL VALVE/ NA1989 outlet

14

7012696

VALVE, RELIEF W/Ref. 23

15

7012697

VALVE, RELIEF W/Ref. 23

16

7012698

VALVE, ANTI CAV

17

7012699

VALVE, SHUTOFF HYD

18

7012700

PLUG W/Ref. 22

19

7012701

VALVE, RELIEF W/Ref. 23

20

6653123

NUT

21

7012765

RING, BACK-UP

22

O-RING

23

7012763

O-RING

24

7012773

O-RING

25

7012766

O-RING

26

7012698

VALVE, ANTI CAV

27

VALVE, SHUTOFF HYD NLA - Order Ref. 26

28

7012767

SPRING, VALVE

29

7012768

POPPET

30

7012769

PLUG

31

7012770

SET SCREW

32

7012771

NUT

33

7012772

PLUG

34

7012774

POPPET
