Артикул
Название
Примечание
Количество
1
7025227
PUMP, HYD PISTON See Illustration HYDRAULIC PISTON PUMP/ NA2146 - Was 7010279 - A
2
MANIFOLD See Illustration MANIFOLD ASSY/ NA2294
3
7151504
INLET, PUMP
4
7214633
HOSE, HYD FORMED Was 7166381 - A
5
29CM1235
BOLT
6
58K225
O RING 10 Was 58K224 - B
7
42HL200
CLAMP, HOSE Was 5HM47 - B
8
7178547
HOSE, HYD ASSY
9
6713504
HOSE
10
7235495
TANK, HYD Was 7166408 - A
11
7166555
TEE
12
7171550
HOSE, HYD FORMED
13
28CM1025
BOLT
14
28CM820
BOLT
15
36K6
CAP
16
43DM10
NUT
17
4DM8
NUT
18
5HM20
CLAMP Was 42HL100 - B
19
6578278
PAD
20
6674264
RETAINER NUT
21
6675859
RETAINER
22
SUPPORT, BRACKET NLA - Order Ref. 36 & 37 - Was 7166465 - C
23
SUPPORT, BRACKET NLA - Order Ref. 36 & 37 - Was 7166571 - C
24
HOSE, HYD NLA - 16'' (406.4 mm) long - Order Ref. 33
25
7178858
FITTING, ADAPTER
25
79K6
O RING 10
26
5HM23
CLAMP
28
7178857
FITTING, ADAPTER
28
79K8
O RING 10
29
17KB0606
FITTING
29
79K6
O RING 10
30
7128723
SCREEN
31
TUBE, SITE GAUGE NLA - Order Ref. 39 & (2) of Ref. 38 - Was 7166537 - C
32
FITTING NLA - Order Ref. 39 & (2) of Ref. 38 - Was 7166625 - C
34
FILTER See Illustration HYDRAULIC CIRCUITRY/ NA2252
35
HOSE, HYD See Illustration HYDRAULIC CIRCUITRY/ NA2255
36
7189558
BRACKET
37
7189559
BRACKET
38
7013179
FITTING
39
7013180
TUBE
40
42HS04
CLAMP, HOSE
Выбрано товаров: 45
