HYDRAULIC PIPING ( VALVE TO TANK )

Запчасти Bobcat 76 HYDRAULIC PIPING ( VALVE TO TANK ) WORK EQUIPMENT CONTROL SYSTEM

Схема запчастей Bobcat 76 - HYDRAULIC PIPING ( VALVE TO TANK ) WORK EQUIPMENT CONTROL SYSTEM
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

6638422

NIPPLE

2

6637417

O-RING

3

6637605

HOSE

4

6637625

CLAMP

5

CONNECTOR Was 20N-62-44230

6

6637417

O-RING

7

6649137

HOSE

8

6637623

CLAMP

9

6637653

TUBE

10

6637673

CONNECTOR

11

6637661

SLEEVE

12

6637664

NUT

13

6637603

HOSE

14

6637625

CLAMP

15

6638423

TUBE
