Запчасти Bobcat 76 BUCKET AND LINK USA SPEC. OPTIONAL PARTS, MARK PLATE

1

6642724

BUCKET 450mm width, 0.1 cubic meters

2

6638496

EDGE (welded)

3

6638599

EDGE side (welded)

4

6638490

LEVER

5

TOOTH NLA - Was 6637819 - A

6

6637168

BOLT

7

6640843

NUT Was 6637820 - A

8

6638499

LINK

9

6637520

BUSHING

10

6637531

SEAL, DUST

11

6638487

SHIM 1.00mm

12

6638488

PIN

13

6637430

FITTING

14

6645857

BOLT

15

6637108

NUT

16

6638497

LINK l. h.

17

6638498

LINK r.h.

18

6638487

SHIM 1.00mm

19

6638489

PIN

20

6637430

FITTING

21

6637241

LOCK

22

6636966

BOLT

23

6637135

WASHER
