Запчасти Bobcat 56 HYDRAULIC PIPING (TRAVEL MOTOR LINE) (LOWER) UNDERCARRIAGE

1

TUBE Was 20M-62-41111

2

TUBE Was 20M-62-41121

3

TUBE Was 20M-62-41131

4

TUBE Was 20M-62-41141

5

6638411

CONNECTOR

6

6638057

NIPPLE

7

6637371

O-RING

8

TUBE Was 20M-62-41151

9

TUBE Was 20M-62-41161

10

6638397

NIPPLE

11

6637369

O-RING

12

6638069

TUBE

13

6638078

ELBOW

14

TRAVEL MOTOR ASS'Y Was 20M-60-40100

15

6638396

PLUG

16

6637369

O-RING

17

6637061

BOLT

18

6637135

WASHER

19

6642316

JOINT, SW See Illustration SWIVEL JOINT/ 6401

20

6636960

BOLT

21

6637134

WASHER

22

6638070

BRACKET

23

6637135

WASHER

24

6637108

NUT
