Запчасти Bobcat 56 BUCKET AND LINK WORK EQUIPMENT

1

6642375

BUCKET 0.06M3, 350MM width

2

6638142

EDGE welded

3

6637821

TOOTH welded

4

6638133

EDGE side - welded

5

6638490

LEVER (with screw & nut)

6

6638139

LINK ASSEMBLY

6

6645749

LINK

7

6637520

BUSHING

8

6637531

SEAL, DUST

9

6638487

SHIM 1,00mm

10

6638132

PIN

11

6637430

FITTING

12

6636976

BOLT

13

6637108

NUT

14

6638140

LINK l. h.

15

6638141

LINK r.h.

16

6638130

PIN

17

6638131

PIN

18

6637430

FITTING

19

6637241

LOCK

20

6636966

BOLT

21

6637135

WASHER
