Запчасти Bobcat 442 AIR CONDITIONER 5223 11755 & Above MAIN FRAME

1

6190271020

BRACKET

2

1008707324

BOLT

3

1343707059

WASHER

4

6190271015

BRACKET

5

1008707424

BOLT

6

6190271010

LEVER

7

1008707923

BOLT

8

1290707020

WASHER

9

1212251013

NUT

10

1007707625

BOLT

11

5411661981

PULLEY

12

1490953883

V-BELT

13

5411661935

SUCTION FILTER

14

1934060170

FITTING

15

1915060567

FITTING

16

0190272250

AIR CONDITIONER W/Ref. 17, 18, 19, 47-50

17

5436662001

CONDENSOR

18

7022922

EVAPORATOR Was 5436662033 - A

19

5436662003

COMPRESSOR, A/C

20

0190272051

HOSE SET W/Ref. 21, 22, 23, 24

21

5436662012

HOSE

22

5436662011

HOSE

23

5436662013

HOSE Uses 5426662098 O-rings

24

5436662010

HOSE

25

5000136820

HOSE CLIP

26

5000210400

HOSE CLIP

27

1343707057

WASHER

28

1007707719

BOLT

29

5000210450

HOSE CLIP

30

6190272009

PLATE

31

5354600010

RUBBER PROFILE

33

1008707213

BOLT

34

1008707817

BOLT

35

1290707014

WASHER

36

6190272060

BRACKET SUPPORT

37

1008707318

BOLT

38

6190272012

BRACKET

39

7023313

SEALING SECTION - A

40

5354640128

NEOPRENE STRIP

41

5354640120

RUBBER

42

1212251009

NUT

44

0190272020

HARNESS

45

5653093560

BINDER

46

5350650280

BINDER

47

1212251011

NUT

48

5436662004

DRIER, A/C ASSY

49

5436662005

BRACKET

50

5436662006

PRESSURE SWITCH

51

0190371015

INSULATION

52

6183772012

BRACKET

53

1008707018

BOLT
