1
6675859
RETAINER
2
6688385
HYD FILTER ASSY See Illustration HYDROSTATIC OIL FILTER/ NA1844
2
6661248
FILTER, OIL HYD 12 #3 media - 152,4 mm (6'') long
3
7015668
MOUNT, STRAP TIE push in - Use W/tie strap - Was 6678666 - B
4
6678818
MOUNT
5
6685156
RETAINER
6
6689664
OIL COOLER
7
6715715
FITTING
7
79K12
O RING 10
8
6806443
GROMMET
9
7124101
HOSE ASSY
10
7137752
MOUNT, W/A hyd filter
11
7127701
PLATE, DRIP
12
7160635
HOSE, HYD FORMED Was 7128764 - A
13
7167239
HOSE, HYD FORMED Was 7143335 - A
14
7128767
TUBELINE
15
7134514
HOSE ASMBLY
16
18KB1212
FITTING, HYD ELBOW
16
79K12
O RING 10
17
24K2
PLUG
17
79K3
O RING 10
18
26GM8020
SCREW
19
21CM820
BOLT
20
29CM820
SCREW
21
30H60
CLIP
22
35C612
BOLT
23
43DM8
NUT
24
51DM8
NUT
25
5HM35
HOSECLAMP
26
6E6
WASHER
27
6660267
VALVE See Illustration SELECTOR VALVE/ B13660
28
6808717
CLIP
29
WIRE ROPE NLA - 14'' (355 mm) long - Order Ref. 47 & 48
30
6674264
RETAINER NUT
31
7130699
PLATE
32
15KB1012
FITTING, HYD CONNECTOR
32
79K12
O RING 10
33
15KB1212
FITTING, HYD CONNECTOR
33
79K12
O RING 10
34
17KB1012
FITTING, HYD ELBOW
34
79K12
O RING 10
35
7135043
TEE
35
79K10
O RING 10
36
28CM1030
BOLT
37
29CM850
SCREW
38
51DM10
NUT
39
HOSE
40
HOSE
41
6688388
VALVE, CONTROL See Illustration CONTROL VALVE/ MS1430
42
7134565
ELBOW
42
79K10
O RING 10
43
16KB1010
FITTING, HYD ELBOW
43
79K10
O RING 10
44
6688051
PUMP See Illustration HYDRAULIC PISTON PUMP/ MS2288
45
7123787
INLET
46
7130718
HOSE
47
6558309
WIRE ROPE bulk - sold per foot
48
6558310
SLEEVE
49
6727869
SENDER,HYD TEMP
50
26GM10020
BOLT
