Запчасти Bobcat 331 PISTON PUMP ASSY HYDRAULIC SYSTEM

1

PUMP See Illustration GEAR PUMP/ MS1236 - NLA - W/Ref. 2 - 43 & gear pump - order 6680010 - Was 6676165 - A

1

6680010

PUMP, HYD

2

HOUSING NSS - Order Ref. 1

3

CONE NSS - Order Ref. 10

4

6678578

SPACER

5

6678581

O-RING

6

6678577

COVER Was 6678571 - D

7

6678580

SCREW

8

6679470

BEARING

9

6679471

RETAINER ring

10

6678579

BEARING W/Ref. 3

11

HANGER NSS - Order Ref. 46

12

6677375

SHAFT Assy - W/Refs. 8, 9

13

6679474

RETAINER

14

6679469

CASE

15

6679473

O-RING

16

6679472

SEAL

17

6678576

SHAFT Was 6679468 - A

18

6677377

ROTARY group

19

6678592

PLATE

20

6678591

HOUSING

20

6678593

DOWEL PIN

20

6678595

PLUG

20

6678597

ORIFICE

21

6678594

SCREW 8mm x 20mm

21

6678599

SCREW 8mm x 45mm

21

6678600

SCREW 8mm x 55mm

22

6678605

SCREW Was 6678619 - A

23

6678620

NUT

24

6678614

COVER

25

6678618

O-RING

26

6678615

SEAT spring

27

6678621

SHIM 0.1

27

6678622

SHIM 0.2

27

6678623

SHIM 0.5

27

6678624

SHIM 1

28

6678651

SEAT

29

6678616

SPRING

30

6678596

BEARING

31

6678650

PISTON

32

6678607

SPRING

33

6678606

SEAT

34

6678598

O-RING

35

6678605

SCREW

36

6678601

COVER

37

6678603

PIN

38

6678604

PIN

39

6678609

O-RING

40

6678610

O-RING

41

6678608

O-RING

42

6678611

ORIFICE

43

6678649

VENT air

44

6686060

GASKET

45

6677777

SEAL KIT

46

6677376

HANGER Ref. 4 - 7, 10 & 11
