Запчасти Bobcat 220 BOOM, ARM, BUCKET, SWIVEL & TRAVEL CONTROLS (S/N 508212952 & Above) WORK EQUIPMENT

1

6539924

CONSOLE

2

6586572

ANGLE lever lock-out - Was 6539916 - A

3

6587150

ARM Was 6536570 - A

4

6536810

CAM

5

6536809

LEVER

6

1DM12

LOCK NUT

7

1CM816

BOLT

8

661846

BOLT shouldered

8

661846

BOLT

9

85D6

NUT, 5

10

4CM845

BOLT

11

1DM8

NUT

12

SPRING NLA - Was 6537016 - A

13

6587059

LEVER

14

1CM1055

BOLT

15

6536801

BUSHING

16

6536545

SLEEVE

17

58K015

O-RING 10

18

6536803

WASHER wave

19

6536802

WASHER

20

27E6

WASHER 5

21

49DM10

NUT

22

6651530

SNAP RING

23

6536531

BALL JOINT

24

1DM10

NUT

25

6539774

ROD

26

6539776

ROD

27

6536536

ROD

28

6536549

YOKE

29

6536543

PIN

30

1F212

PIN

31

6539918

LEVER

32

1CM1025

BOLT

33

6658184

KNOB

34

6586312

COVER

35

1CM620

BOLT

36

BOOT NLA - Was 6537000 - A

37

6537023

RETAINING RING boot retaining

38

58G808

SCREW

39

6537024

COVER

40

6658108

KNOB

41

6536837

COVER

42

6587058

LEVER Was 6539796 - A

43

15EM60

WASHER

44

25EM18000

WASHER

45

6660787

RING tolerance

46

2C512

SCREW

47

6539771

LEVER bellcrank

48

6539773

LEVER bellcrank

49

6539780

LEVER bellcrank

50

6539775

ROD

51

1CM820

BOLT

52

10H25

FITTING, GREASE 5

53

VALVE See Illustration CONTROL VALVE ASSEMBLY/ D2043 NLA - Was 6655456 - A

54

15EM80

WASHER
