Запчасти Bobcat 130 WORK EQUIPMENT CONTROL LINKAGE For Boom & Bucket 1/2 CONTROL SYSTEM

1

6639182

LEVER

2

6637894

BEARING

3

6639185

SHAFT

4

6637201

PIN, COTT

5

6639171

BLOCK

6

6636974

BOLT

7

6637157

WASHER

8

6639713

LEVER

9

6639287

BEARING

10

6639726

ROD

11

6639727

ROD

12

6637113

NUT

13

6637307

END

14

6636968

BOLT

15

6637316

SHIM

16

6637100

NUT LH threads

17

6637308

ROD END

18

6636968

BOLT

19

6637316

SHIM

20

6637100

NUT LH threads

21

6637271

YOKE

22

6637258

PIN

23

6637199

PIN, COTTER

24

6639725

SHIELD

25

6639724

SHIELD

26

6636968

BOLT

27

6637157

WASHER

28

6639723

SHIELD

29

6636960

BOLT

30

6637134

WASHER
