INSTRUMENT PANEL 3/3 Radio-less Without Swing Mechanical Brake (except Japan)

Запчасти Bobcat 130 INSTRUMENT PANEL 3/3 Radio-less Without Swing Mechanical Brake (except Japan) ENGINE RELATED PARTS AND ELECTRICAL SYSTEM

Схема запчастей Bobcat 130 - INSTRUMENT PANEL 3/3 Radio-less Without Swing Mechanical Brake (except Japan) ENGINE RELATED PARTS AND ELECTRICAL SYSTEM
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

6639777

BOX

2

6637703

GROMMET

3

6636967

BOLT

4

6637157

WASHER

5

6639203

PANEL

6

6636957

BOLT

7

6637156

WASHER

8

6639880

COVER

9

6636957

BOLT

10

6637156

WASHER

11

PLATE Was 205-06-72181

12

6637026

SCREW

13

6637125

WASHER

14

6637143

WASHER
