Запчасти Bobcat 130 CONTROL VALVE, L.H. 3/3 HYDRAULIC SYSTEM

1

VALVE ASSY See Illustration CONTROL VALVE, L.H./ B26015 See Illustration CONTROL VALVE, L.H./ B26014 control - L.H. - Was 709-26-11303

1

6640550

VALVE ASY See Illustration CONTROL VALVE, L.H./ B26015 See Illustration CONTROL VALVE, L.H./ B26014 control - L.H.

1

VALVE ASSY suction & safety - Was 709-20-61102

1

6640527

VALVE ASSY suction & safety

1

VALVE ASSY suction & safety - Was 709-20-61301

1

6640529

VALVE ASSY suction & safety

1

6646117

SLEEVE Was 709-20-61110

2

6640542

O-RING

3

VALVE Was 709-20-61121

4

SEAL Was 709-20-61230

5

POPPET Was 709-20-61130

6

6646875

SPRING

7

6646120

PISTON

8

O-RING Was 709-20-61210

9

SEAL Was 709-20-61220

10

6637368

O-RING

11

6637394

RING, BAC

12

NUT Was 709-20-61170

12

NUT Was 709-20-61171

13

SPRING Was 709-20-61160

14

6640530

VALVE ASSY suction

14

SLEEVE Was 709-20-61110

15

6640542

O-RING

16

VALVE Was 709-20-61180

17

SEAL Was 709-20-61230

18

SPRING Was 709-20-61160

19

6643221

VALVE ASSY 300kg/cm2

19

SLEEVE Was 709-20-51113

20

VALVE Was 709-20-51260

21

6640526

SPRING

22

6640217

RING

23

6640258

POPPET

24

6640525

SPRING

25

SCREW Was 709-20-51280

26

6637114

NUT

27

6637335

O-RING

28

6640243

O-RING

29

6640259

RING

30

6637411

O-RING
