Запчасти Bobcat 116 BOOM SWING CONTROL LEVER CONTROL SYSTEM AND REVOLVING FRAME

1

BRACKET Was 20T-43-41310

2

6637894

BEARING

3

SHAFT Was 20S-43-31320

4

6637173

KEY

5

6642811

LEVER

6

LEVER Was 20S-43-31350

7

6636960

BOLT

8

6637134

WASHER

9

LEVER Was 20T-43-41320

10

6637894

BEARING

11

SHAFT Was 20S-43-31330

12

6637173

KEY

13

6642907

LEVER

14

LEVER Was 20S-43-31360

15

6636960

BOLT

16

6637134

WASHER

17

6636968

BOLT

18

6636975

BOLT

19

6637157

WASHER

20

6649139

KNOB

21

6638686

COVER

22

6638692

HINGE

23

6636958

BOLT

24

6637156

WASHER

25

6642917

ROD

26

6638691

YOKE L.H. thread

27

NUT, L.H. THREAD Was 01508-41006

28

6637255

PIN

29

6637196

PIN, COTT

30

6637248

PIN

31

6637193

PIN
